Overview

NVIDIA® Quadro® 6000 - World's First 6 GB Professional Graphics Solution



Offering 6 GB of GDDR5 graphics memory, 448 NVIDIA CUDA™ parallel processing cores and built on the innovative Fermi architecture, the NVIDIA Quadro 6000 by PNY is a true technological breakthrough delivering excellent performance across a broad range of design, animation and video applications. Using the Quadro 6000 graphics solution, your work flows — you can design, render and deliver higher quality projects in less time.

The NVIDIA Quadro 6000 by PNY offers ECC memory and fast double precision to ensure the accuracy and fidelity of your work. Quadro is designed to run computationally intensive applications such as ray tracing, video processing and computational fluid dynamics; supports DirectX 11.0, OpenGL 4.1 and Shader Model 5.0 hardware acceleration, and drives a variety of display types including: CRTs, Digital Flat Panels, Projectors and HDTVs.

Specification : NVIDIA Quadro 6000

Memory 6 GB GDDR5
Memory Interface 384-bit
Memory Bandwidth 144 GB/sec
CUDA Parallel Processing Cores 448
ECC (Error Correcting Code) Yes
High Performance Double Precision Yes
Maximum Power Consumption 204 W
Energy Star Compliant Yes
Physical Dimensions 4.376" H x 9.75" L Dual Slot
Display Connectors DVI-DL + DP + DP + ST
Number of Displays Supported 2
DP Yes
DVI Yes
VGA
Yes
Graphics Bus PCI Express 2.0 x16
Thermal Solution Active
3D Vision Pro Support via 3-pin Mini-DIN
G-Sync Version Available
HD SDI Capture/Output Version Available
Maximum Digital Resolution 2560 x 1600 at 60Hz
Graphics APIs OpenGL 4.1, DirectX 11.0 and Shader Model 5.0
Compute APIs NVIDIA CUDA, DirectCompute and OpenCL
Warranty 3 Years

* Note: With ECC on, a portion of the dedicated memory is used for ECC bits, so the available user memory is reduced by 12.5%. (e.g. 3 GB total memory yields 2.625 GB of user available memory.)

3D Graphics Architecture

    Scalable geometry architecture
    Hardware tessellation engine
    NVIDIA® GigaThread™ engine with dual copy engines
    OpenGL 4.1, DirectX 11.0 and Shader Model 5.0
    Optimized compiler for Cg and Microsoft HLSL
    Up to 16K x16K texture and render processing
    Transparent multisampling and super sampling
    16x angle independent anisotropic filtering
    128-bit floating point performance
    32-bit per-component floating point texture filtering and blending
    64x full scene antialiasing (FSAA)
    Decode acceleration for MPEG-2, MPEG-4 Part 2 Advanced Simple Profile, H.264, MVC, VC1, DivX (version 3.11 and later), and Flash (10.1 and later)
    DivX (version 3.11 and later), and Flash (10.1 and later)
    Blu-ray dual-stream hardware acceleration (supporting HD picture-in-picture playback)

NVIDIA CUDA Parallel Processing Architecture

    API support includes CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran
    NVIDIA® Parallel DataCache™ hierarchy (configurable L1 and unified L2 caches)
    ECC (Error Correction Code) memory
    64 KB of RAM (configurable partitioning of shared memory and L1 cache)
    Fully IEEE 754-2008 compliant fast 32- and 64-bit double precision floating point computation
    Dual Warp Scheduler (schedules and dispatches simultaneously instructions from two independent warps)

Advanced Display Features

    30-bit color (10-bit per each red, green, blue channel)
    Support for any combination of two connected displays
    Dual DisplayPort resolution up to 2560 x 1600 at 60Hz or 1920 x 1200 at 120Hz
    DisplayPort 1.1a with HDCP support
    Single DVI-DL output up to 2560 x 1600 at 60Hz or 1920 x 1200 at 120Hz
    DisplayPort to VGA adapter sold separately, PNY PN 91007808-T
    DisplayPort to DVI-DL adapter sold separately, PNY PN 91008126
    DisplayPort to HDMI adapters available from 3rd parties
    Full OpenGL quad buffered stereo support
    NVIDIA® 3D Vision™ Pro support via dedicated 3-pin mini-DIN stereo bracket
    Underscan/overscan compensation and hardware scaling
    NVIDIA® Mosaic™ multi-display technology
    NVIDIA® nView® multi-display technology

DisplayPort and HDMI Digital Audio

    Support for Dolby Digital (AC3), DTS 5.1, Multi-channel (7.1) LPCM, Dolby Digital Plus (DD+), and MPEG-2/MPEG-4 AAC
    Data rates of 44.1 KHz, 48 KHz, 88.2 KHz, 96 KHz, 176 KHz, and 192 KHz
    Word sizes of 16-bit, 20-bit, and 24-bit
    HDMI digital audio requires the purchase of a 3rd party DisplayPort to HDMI adapter


GPU FEATURES

Next-Generation NVIDIA® CUDA™ Architecture
Breakthrough NVIDIA CUDA parallel computing architecture, code named Fermi, tightly integrates advanced visualization and compute features delivering performance that greatly accelerates professional workflows.

NVIDIA Parallel DataCache™
Supports a true cache hierarchy combined with on-chip shared memory. L1 and L2 caches drive exceptional throughput, accelerating features such as real-time ray tracing, physics and texture filtering.

6 GB of GDDR5 Memory with Ultra-Fast Bandwidth
Industry's first GPU with 6 GB of memory and memory bandwidth of 144 GB/s for display of large models and complex scenes, as well as computation of massive datasets.

Fast 64-Bit Floating Point Precision
Industry's fastest double precision floating point performance enabling accurate results on mission-critical applications, including computer-aided-design, finite element analysis to computational fluid dynamics.

Error Correcting Code (ECC) Memory
Meets strict requirements for mission critical applications with uncompromised computing accuracy and reliability for workstations. Offers protection of data in memory to enhance application data integrity.

NVIDIA GigaThread™ Engine
Provides up to 10x faster context switching compared to previous generation architectures, concurrent kernel execution, and improved thread block scheduling.

Dual Copy Engines
Enables the highest rates of parallel data processing and concurrent throughput between the GPU and host, accelerating techniques such as ray tracing, color grading and physical simulation.

NVIDIA Scalable Geometry Engine™
Dramatically improves geometry performance across a broad range of CAD, DCC and medical applications, enabling you to work interactively with models and scenes that are an order of magnitude more complex than ever before.

Fast 3D Texture Transfer
Fast transfer and manipulation of 3D textures resulting in more interactive visualization of large volumetric datasets.

Hardware 3D Window Clipping
Hardware accelerated clip regions (data transfer mechanism between a window and the frame buffer) improve overall graphics performance by increasing transfer speed between color buffer and frame buffer.

Unified Driver Architecture (UDA)
The NVIDIA UDA guarantees forward and backward compatibility with software drivers. Simplifies upgrading to a new solution because all Quadro products work with the same driver software.

Ultra-Quiet Design
Acoustics lower than 28db for an ultra-quiet desktop environment.

IMAGE QUALITY

Full-Scene Antialiasing (FSAA)
Up to 64X FSAA dramatically reduces visual aliasing artifacts or "jaggies," resulting in unparalleled image quality and highly realistic scenes.

GPU Tessellation with Shader Model 5.0
Quadro Tessellation Engines automatically generate finely detailed geometry, for cinematic quality environments and scenes, without sacrificing performance.

16K Texture and Render Processing
The ability to texture from and render to 16K x 16K surfaces. Beneficial for applications that demand the highest resolution and quality image processing.

NVIDIA High Precision High Dynamic Range (HDR) Technology
Sets new standards for image clarity and quality through floating point capabilities in shading, filtering, texturing, and blending. Enables unprecedented rendered image quality for visual effects processing.

DISPLAY FEATURES

High-Quality Display Connectors
Attaches to ultra-high-resolution digital panels producing phenomenal photorealistic image quality from a range of display connectors. The Quadro 6000 GPU simultaneously supports two active display channels including DVI-I dual link and DisplayPort at resolutions up to 2560 x 1600 at 60Hz. The included DVI to VGA adapter supports resolutions up to 2048 x 1536 at 85Hz. HDMI 1.3a compliant displays can be driven with a 3rd party adapter (must be purchased separately) at resolutions up to 1920 x 1080 at 60Hz.

30-Bit Color Fidelity
30-bit color fidelity (10-bits per color) enables billions rather than millions of color variations for rich, vivid image quality with the broadest dynamic range.

SDI I/O and SDI Versions Available
Industry's only GPU-accelerated solution for real-time acquisition, processing, and delivery of high-resolution SDI video, across traditional and now 3D video broadcast environments. Supports uncompressed 8-, 10- and 12-bit SDI input and output (PNY PN VCQ6000SDI-IO-PB) or output only (PNY PN VCQ6000SDI-PB).

G-Sync Version Available
The G-Sync option version of the Quadro 6000 (PNY PN VCQ6000G-PB) is an advanced solution that ensures frame synchronization between GPUs and provides a way to synchronize to an external source (also known as house sync). G-Sync allows advanced visualization systems to utilize many projectors or displays in unison delivering unprecedented levels of realism and betters ways to collaborate.

NVIDIA 3D Vision Pro™ Stereoscopic Solution
Advanced active shutter glasses deliver crystal-clear stereoscopic 3D visualization for the most immersive experience. RF technology enables a range of environments ranging from collaborative work spaces to theaters. 3D Vision Pro solution sold separately.

OpenGL Quad Buffered Stereo Support
OpenGL Quad Buffered Stereo offers professional applications the capability of smooth and immersive 3D Stereo experience.

Professional 3D Stereo Synchronization
Enables robust control of stereo effect through a dedicated 3-pin mini-din connection between the graphics card and 3D stereo hardware.


SOFTWARE SUPPORT

Programming the CUDA Parallel Computing Architecture
General purpose GPU computing using standard programming languages like C/C++ and Fortran, and emerging APIs such as OpenCL and Direct Compute. This broad adoption of CUDA is accelerating techniques like ray tracing, video and image processing, and computation fluid dynamics.

Cg Programming
Programmable GPU leverages Cg high-level, open-standard shading language to enable the creation and integration of real-time photorealistic effects into 3D models, scenes and designs.

Microsoft® Windows® 7 Support
Take advantage of all the new and compelling features included with Windows 7, delivering unprecedented application performance, advanced visual realism, and premium reliability with superior application compatibility on mobile and desktop workstations.

Shader Model 5.0 Programmability
Infinite length vertex programs and dynamic flow control remove the previous limits on OpenGL and DirectX shader programs, delivering sophisticated effects never before imagined.

NVIDIA Graphics API Extensions
NVIDIA provides a set of extensions to standard graphics APIs for Linux and Windows, enabling applications to take maximum advantage of state-of-the-art GPU capabilities.

NVIDIA Application Acceleration Engines Support
Supercharge application performance and capabilities with highly optimized software modules, including SceniX™, OptiX™, and CompleX™, for advanced creative and investigative possibilities.

NVIDIA Mosaic Mode Technology
NVIDIA Mosaic Mode enables transparent scaling of any application across up to 8 display channels, while delivering full performance.

 NVIDIA NVIEW™ Multi-Display Technology
NVIEW advanced display software delivers maximum flexibility for single-large display or multi-display options, providing unprecedented end-user control of the desktop experience for increased productivity.



Product Specs

Specification : NVIDIA Quadro 6000

Memory 6 GB GDDR5
Memory Interface 384-bit
Memory Bandwidth 144 GB/sec
CUDA Parallel Processing Cores 448
ECC (Error Correcting Code) Yes
High Performance Double Precision Yes
Maximum Power Consumption 204 W
Energy Star Compliant Yes
Physical Dimensions 4.376" H x 9.75" L Dual Slot
Display Connectors DVI-DL + DP + DP + ST
Number of Displays Supported 2
DP Yes
DVI Yes
VGA
Yes
Graphics Bus PCI Express 2.0 x16
Thermal Solution Active
3D Vision Pro Support via 3-pin Mini-DIN
G-Sync Version Available
HD SDI Capture/Output Version Available
Maximum Digital Resolution 2560 x 1600 at 60Hz
Graphics APIs OpenGL 4.1, DirectX 11.0 and Shader Model 5.0
Compute APIs NVIDIA CUDA, DirectCompute and OpenCL
Warranty 3 Years

* Note: With ECC on, a portion of the dedicated memory is used for ECC bits, so the available user memory is reduced by 12.5%. (e.g. 3 GB total memory yields 2.625 GB of user available memory.)
